Plastic and Resin Automatic Melt Flow Testing Machine with Imported Raw Material

Name: Plastic and Resin Automatic Melt Flow Testing Machine with Imported Raw Material
Brand: Guangdong Guangce Instrument Technology Co., Ltd
SKU: GC-MI-EP
Availability: InStock

Brand Name:	GC
Model Number:	GC-MI-EP
MOQ:	1 Set
Price:	Negotiated
Delivery Time:	In stock
Payment Terms:	TT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Model NO.:

GC-MI-EP

Max Diameter Of Workpiece:

<500mm

Mass Scope Of Workpiece:

<900kg

Type:

Plastic And Rubber Test Machine

Maxcapacity:

<1000KN

Accuracy Grade:

0.5

Load Way:

Electronic Load

Loading Method:

Dynamic Load

Display:

Digital

Control:

Computer Control

Weight:

100-500Kg

Power Source:

AC220V

Oil Cylinder Position:

Under

Thermal Recovery Time:

<4min

Time Resolution:

0.1s

Display Mode:

Digital Touch Screen

Transport Package:

Wooden Package

Specification:

65*55*140

Trademark:

Origin:

China

Package Size:

65.00cm * 55.00cm * 140.00cm

Package Gross Weight:

150.000kg

Customization:

Available

Warranty:

12 Months

Packaging Details:

Wooden package

Supply Ability:

100 Sets

Highlight:

Plastic Melt Flow Testing Machine

Automatic Melt Flow Testing Machine

Resin Melt Flow Testing Machine

Product Description

-The Automatic melt flow index tester is a euqipment used to measure the melt flow index (MFI) of polymer and engineering materials. The MFI is a measure of the flow properties of a polymer when it is melted under specified conditions.
-The automatic melt flow index tester typically consists of a heating unit to melt the polymer, a piston to extrude the molten polymer through a die, and a load cell to measure the force required to extrude the polymer.
-This machine can provide high accurate and repeatable measurements of the MFI, which is important for quality control and process optimization in the plastics industry.

Product name	Automatic Melt Flow Index Tester
Measuring	MFR/MVR
Corrosion resistance	Yes
Display mode	Color Touch Screen
Cutting method	Hand automatic integration
Temperature control range	100ºC-450ºC
Temperature control accuracy	±0.2ºC
Temperature control unformity	±1ºC
Temperature recovery time	<4min
Time resolution	0.1S
Computer output	Connectable
Die	Carbon tungsten steel 2.095±0.005mm
Bucket	Imported Hastelloy 9.550±0.025mm
Power	AC220V±10% 50HZ

Standrad:

GB/T3682-2000	Determination of thermoplastic melt flow rate and melt volume flow rate
ISO 1133:1997	Determination of thermoplastic melt mass flow rate MFR and melt volume flow rate MVR
ASTM D1238	Standard test method for melt flow rate of thermoplastics using an extrusion plastometer.

Melt index accessories list:

Item	Name	Unit	Quantity	Remark
1	Host	set	1	Printer included
2	Weight	set	A total of 8 levels: 0.325 kg , 1.200 kg , 2.160 kg , 3.800 kg , 5.000 kg , 10.000 kg , 12.000 kg , 21.600 kg	(1# is within level 1 load)
3	Weight tray	pieces	1	Within level 1 load
4	Piston rod	pieces	1	Within level 1 load
5	Die	pieces	1	Tungsten carbide
6	Loading hopper	pieces	1	Stainless steel
7	Loading lever	pieces	1
8	Barrel cleaning rod	pieces	1
9	Die cleaning rod	pieces	1	Stainless steel
10	Gauze	roll	2
11	Print paper	roll	2
12	Other	Certificate of conformity, instruction manual, and a feeding tray
