Impact Testing Machine Imported Digital Encoder Plastic Izod Pendulum Equipment

Name: Impact Testing Machine Imported Digital Encoder Plastic Izod Pendulum Equipment
Brand: Guangdong Guangce Instrument Technology Co., Ltd
SKU: GC-XBJ
Availability: InStock

Brand Name:	GC
Model Number:	GC-XBJ
MOQ:	1 Set
Price:	Negotiated
Delivery Time:	In stock
Payment Terms:	TT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Model NO.:

GC-XBJ

Max Diameter Of Workpiece:

<500mm

Mass Scope Of Workpiece:

<900kg

Type:

Impact Testing Machine

Maxcapacity:

<1000KN

Accuracy Grade:

0.5

Load Way:

Electronic Load

Loading Method:

Dynamic Load

Display:

Digital

Control:

Computer Control

Weight:

100-500Kg

Power Source:

AC220V

Oil Cylinder Position:

Under

The Pendulum Energy:

1j,2.75j,5.5j

Cutting Method:

Hand Automatic Integration

Angle Accuracy:

0.01j

Transport Package:

Wooden Package

Trademark:

Origin:

China

Package Size:

89.00cm * 40.00cm * 74.00cm

Package Gross Weight:

85.000kg

Customization:

Available

Warranty:

1 Year

Packaging Details:

Wooden package

Supply Ability:

100 Sets

Highlight:

Plastic Izod Pendulum Equipment

Imported Plastic Izod Pendulum Equipment

Product Description

-The digitdl Izod impact testing machine is a device used to measure the impact strength or toughness of a material. It is commonly used in engineering and manufacturing industries to assess the ability of a material to withstand sudden impacts or shocks.The results of Izod impact tests are crucial for ensuring the safety and reliability of products in various applications, such as automotive components, structural elements, and consumer goods.
-The machine consists of a pendulum with a striking edge, which is released from a certain height to strike a notched sample of the material being tested. The pendulum's energy at the point of impact is measured, and this value is used to calculate the material's impact strength.
-

Impact Testing Machine Imported Digital Encoder Plastic Izod Pendulum Equipment 0 .

Product Name	Digital Izod Impact Test Machine
Item	IZOD
The pendulum energy	11J 12J
Display mode	Color touch screen
Cutting method	Hand automatic integration
Pendulum pre-evaluation angle	150ºC
Impact velocity	3.5m/s
Angle accuracy	0.01J
Distance between Pendulum and the impact blade	335mm
Distance between impact blade to upper mouth	22mm
Blade fillet radius	R=0.8±0.2mm
Output method	Printout
Power	220V,50HZ

Impact Testing Machine Imported Digital Encoder Plastic Izod Pendulum Equipment 2

Impact Testing Machine Imported Digital Encoder Plastic Izod Pendulum Equipment 8

Impact Testing Machine Imported Digital Encoder Plastic Izod Pendulum Equipment 10
