Manual Control Rubber Mixing Machine with 50-60HRC Roller Hardness and 750x380x600mm Specification

Name: Manual Control Rubber Mixing Machine with 50-60HRC Roller Hardness and 750x380x600mm Specification
Brand: Guangdong Guangce Instrument Technology Co., Ltd
Price: 3000 USD
Availability: InStock

MOQ:	1
Price:	3000

Detail Information

Product Description

Detail Information

Certification:

CE, ISO

Model NO.:

GC-6015D-3

Control Type:

Artificial

Automatic Grade:

Manual

Power Source:

Electric

Type:

Open Mixing Mill

Working:

High Speed Mixer

Stirring Type:

Spiral

Layout Type:

Horizontal

Mixing Drum Shape:

Disc

Additional Capabilities:

Milling

Operating Type:

Cycle Operating

Mixer Type:

Rubber Mill Mixer

Roller Hardness:

50 ~ 60HRC

Roller Handling:

Mirror Polished Chrome

Safety Devices:

Collision Emergency Stop

Highlight:

50-60HRC Roller Hardness Rubber Mixing Machine

750x380x600mm Specification Open Mill Rubber Mixer

Manual Control Two Roll Mill Machine

Product Description

High Quality Durable Silicone Rubber Mixing Machine

This rubber mixing machine features exposed rollers designed for rubber factories to prepare plasticized rubber, mixed rubber, or heat-cured and extruded materials. The main components consist of two hollow rollers that rotate inward in opposite directions. The front roller (operator side) can be adjusted horizontally, while the rear roller remains fixed. Both rollers operate at different speeds to create strong shearing action for effective mastication or mixing. This machine is also suitable for plastics processing applications.

Key Features

Intuitive operation: Operators can directly observe material mixing and adjust parameters in real-time
Flexible processing: Handles various polymer materials including rubber, plastic, masterbatch, and composites
Precise control: Adjustable roller spacing and temperature for different material requirements
Durable construction: Wear-resistant chrome-plated rollers with mirror finish for extended service life
Easy maintenance: Open design allows cleaning without complex disassembly

Technical Specifications

Item	Specification
Model	GC-6015D-3
Roller diameter	76mm/3in
Roll width	300mm
Mixing capacity (soft rubber)	0.1 ~ 1kg
Material receiving device	SUS304 stainless steel hopper
Roller temperature	Normal temperature or normal temperature -250°C
Temperature uniformity	2.5°C
Thermostat	Omron
Roller speed ratio	1:1.25 (constant speed)
Roller hardness	50 ~ 60HRC
Roller handling	Mirror polished chrome
Roller spacing	0.1 ~ 6mm adjustable
Rotating speed	10-40r/min
Spacing display method	Scale
Safety devices	Collision emergency stop (2 units)
Power	2.2KW
Voltage	1∮, AC220V
Machine size	750(L)×380(W)×600mm(H)
Total weight	≈128kg

About Guangdong Guangce Instrument Technology Co., Ltd.

Based in Dongguan, we are a technology-driven enterprise specializing in R&D, production, OEM, and sales of scientific testing equipment with 17 years of industry expertise. Our capabilities include:

Strong software/hardware R&D supported by experienced technical team
National leader in plastic polymer physical property testing instruments
Compliance with global standards (GB, ASTM, ISO, JIS, EN, DIN, UL)
5,000 square meter facility with 30+ staff (10 R&D, 8 technicians)
Annual production capacity of 2,000+ units
Certifications: ISO9001-2015 and National High-Tech Enterprise (2022)
20+ national utility model patents and software copyrights

Our products serve auto parts, electronics, new energy, plastics, hardware, LED/LCD industries, and research institutions. With branches in Suzhou, Ningbo, and Xiamen, we export to 40+ countries including the U.S., Japan, and Germany.

Frequently Asked Questions

Are you a factory or trading company?

We are a professional manufacturer and provide OEM services to customers. Welcome to visit our company and factory.

Why choose us?

We are a professional OEM manufacturer with 15 years of experience in R&D and production of polymer plastic testing instruments, and can provide production and processing customization.

How can we guarantee the quality?

Always a pre-production sample before mass production and always a final inspection before shipment.

What is your delivery time?

The test machines are mostly in stock, so we can deliver within 3-5 working days after receiving payment. We can also accept urgent orders for prompt shipment.

What is the shipping method?

It could be shipped by sea, by air or by express (EMS, UPS, DHL, TNT, FEDEX etc). Please confirm with us before placing orders.

What about the after-sale service?

Every machine from our factory has 12 months warranty. We also provide life-long paid repair or service.
