800L Programmable Constant Temperature Humidity Chamber Testing Machine

Name: 800L Programmable Constant Temperature Humidity Chamber Testing Machine
Brand: Guangdong Guangce Instrument Technology Co., Ltd
SKU: GC-TH-800Z
Availability: InStock

Brand Name:	GC
Model Number:	GC-TH-800Z
MOQ:	1 Set
Price:	Negotiated
Delivery Time:	In stock
Payment Terms:	TT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Model NO.:

GC-TH-800Z

Warranty:

1 Year

Temperature Range:

-40°~+150°

Humidity Range:

20%~98%

Condensation Method:

Air-Cooled

Transport Package:

Wooden Box Package

Specification:

800L

Trademark:

Origin:

China

Supply Ability:

300 PCS/Month

Packaging Details:

Wooden package

Supply Ability:

100 Sets

Highlight:

800L temperature humidity chamber

Programmable temperature humidity chamber

Programmable low humidity chamber

Product Description

800L Programmable Constant Temperature and Humidity Testing Machine

Introduction

This test chamber provides a simulated environment of high temperature, low temperature, high humidity and low humidity to detect the material and strength of rubber, plastic, electronic products before and after testing. The machine can also simulate the container environment to detect the fading and shrinkage of rubber and plastic under high temperature and high humidity. Test the heat resistance, cold resistance, dry resistance and humidity resistance of various materials. It is suitable for quality control testing of factories in electronics, electrical appliances, batteries, universities, research institutes, inspection and quarantine bureaus, paper products, food, vehicles, auto parts, metals, chemicals, building materials and other industries.

Specifications

Model			GC-TH-800Z
Inner box size WHD (cm)			10010080
Carton size WHD (cm)			155185130
Inner box volume			800L
Temperature and humidity control range			TH: -40ºC~150ºC RH: 20%-98% (Special temperature and humidity specifications can be customized)
Function		Temperature and humidity fluctuation	±0.5ºC; ±2.5% RH.
		Temperature and humidity deviation	±0.5ºC-±2ºC; ±3% RH (>75% RH); ±5% RH (≤75% RH)
		Controller resolution	±0.3ºC; ±2.5% RH
		Controller Brand programmable	Korea TEMI880 touch screen controller
Material	Inner wall		SUS304#steel plate
	Outer wall		SUS304#steel plate mist treatment
	Thermal insulation material		High temperature resistant high density ethyl chloroformed foam insulating material system
air circulation mode			Centrifugal fan-broadband forced air circulation
Cooling mode			Single stage mechanical compression system
Refrigerating machine			Fully enclosed piston French Tecumseh compressor
Refrigerant			R404A or American DuPont environmental refrigerant (R23+R404)
Condensation method			Air-cooled
Heater			Ni-Cr wire heater
Humidifier			Semi-closed steam humidification
Water supply mode			Automatic circulating water supply
Safety device			No fuse switch, (compressor overload, refrigerant high and low pressure, ultra-humidity and over-temperature) protection switch, fuse failure warning system)
Power			220V AC±10% 60HZ

Introduction of Guangdong Guangce Instrument Technology Co., Ltd
