Charpy Izod Testing Machine Impact Test Equipment Touchscreen Display

Name: Charpy Izod Testing Machine Impact Test Equipment Touchscreen Display
Brand: Guangdong Guangce Instrument Technology Co., Ltd
SKU: GC-JZL-5D
Availability: InStock

Brand Name:	GC
Model Number:	GC-JZL-5D
MOQ:	1 Set
Price:	Negotiated
Delivery Time:	In stock
Payment Terms:	TT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Model NO.:

GC-JZL-5D

Transport Package:

Wooden Box Packaging

Specification:

85KG

Trademark:

Origin:

Guangdong

Customization:

Available

After-sales Service:

Online Guidance

Warranty:

1 Year

Packaging Details:

Wooden package

Supply Ability:

100 Sets

Highlight:

Charpy izod testing machine

Touchscreen izod testing machine

Charpy izod impact test equipment

Product Description

Digital Charpy Impact Test Machine

Charpy Izod Testing Machine Impact Test Equipment Touchscreen Display 0

Model: GC-JZL

1. Product Introduction

The digital display simply supported beam impact tester is mainly used for the determination of the impact toughness of non-metallic materials such as hard plastics, reinforced nylon, glass fiber reinforced plastics, ceramics, cast stones, and electrical insulating materials. It is an ideal test equipment for chemical industry, scientific institutions, colleges and universities, quality inspection and other departments.

2. Test Standards

ISO179-2000 Determination of Impact Strength of Plastic-Hard Material Simply Supported Beams
GB/T1043-2008 Impact Test Method for Rigid Plastic Simply Supported Beam
JB/T8762-1998 Plastic Simply Supported Beam Impact Testing Machine
GB/T18743-2002 The Impact Test Method of Simply Supported Beam of Thermoplastic Pipe for Fluid Transport (applicable to pipe fittings.)

3. Features

Use high-strength carbon fiber swing rod to improve the rigidity of the material

Imported high-resolution digital encoder

Chinese and English operating interface can be selected, test results can be selected in J/m, kg-cm/cm, ft-ib/in and other units

4. Parameters

Item	Simple supported beam
Model	GC-JZL-5D
The pendulum energy	1J,2J,4J,5J
Display mode	Color touch screen
Pendulum pre-evalution angle	150ºC
Impact velocity	2.9m/s
Pendulum center distance	230mm
Angel accuracy	0.01°
Energy accuracy	0.01J
Jaw support spacing	40mm,60mm,70mm,95mm(customizable)
Supporting blade fillet radius	R=1mm
Impact angle	30°
Fillet radius of impact blade	R=2mm±0.5mm
Output method	Printout
Power	220V50HZ

Charpy Izod Testing Machine Impact Test Equipment Touchscreen Display 1

Charpy Izod Testing Machine Impact Test Equipment Touchscreen Display 5
