Electronic Glow Wire Flammability Test Apparatus Horizontal Burning Tester Chamber

Name: Electronic Glow Wire Flammability Test Apparatus Horizontal Burning Tester Chamber
Brand: Guangdong Guangce Instrument Technology Co., Ltd
SKU: GC-ZRS-C
Availability: InStock

Brand Name:	GC
Model Number:	GC-ZRS-C
MOQ:	1 Set
Price:	Negotiated
Delivery Time:	In stock
Payment Terms:	TT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Model NO.:

GC-ZRS-C

Max Diameter Of Workpiece:

<500mm

Mass Scope Of Workpiece:

<900kg

Type:

Flame Retardant Test Chamber

Maxcapacity:

<1000KN

Accuracy Grade:

0.5

Load Way:

Electronic Load

Loading Method:

Dynamic Load

Display:

Digital

Weight:

100-500Kg

Power Source:

AC220V

Oil Cylinder Position:

Under

Timer:

0-99 Minutes

Temperature Tolerance Error:

500~750º

Glow Wire Moving Speed:

10mm/S-25mm/S

Glow Wire U-Shaped Head:

4mm Imported Nickel/Chromium (80/20) Wire

Transport Package:

Wooden Package

Specification:

110*65*125cm

Trademark:

Origin:

China

Package Size:

110.00cm * 65.00cm * 125.00cm

Package Gross Weight:

220.000kg

Customization:

Available

Warranty:

1 Year

Packaging Details:

Wooden package

Supply Ability:

100 Sets

Highlight:

Glow Wire flammability test apparatus

electronic flammability test apparatus

electronic horizontal burning tester

Product Description

Glow Wire Flame Test Chamber With Manual Control

This testing machine is mainly used to simulate the thermal stress caused by heat sources or ignition sources such as hot components or overloaded resistors in a short time under fault or overload conditions of electronic and electrical components or parts, and use simulation technology to evaluate the fire hazard. It is applicable for plastic and non-metal insulating material parts used in electrical and electronic products, components, and household appliances, such as switch housings, relay sockets, etc.

Test Standards:

IEC60695-2-10/11/12/13 Fire hazard test methods for electronic and electrical products
IEC60884-1-2002 Plug sockets for home and similar purposes
GB2099.1-2008 Plug sockets for home and similar purposes
IEC60335-1 Safety of household appliances and similar appliances
GB4706.1-2005 Safety of household appliances and similar appliances
VDE0620-2010 General requirements for household and similar plugs and sockets
GB/T5169.10-11-2006 Glow wire device and general test method

Product name	Touch Screen Glow Wire Test Apparatus
Control mode	Touch Screen Control
Outer box dimensions	11065125(cm)
Glow wire temperature	Adjust from room temperature to 1100°C
Glow wire moving speed	10mm/s-25mm/s
Box volume	≥0.5m³,With glass observation door
Fuel	Butane
Thermocouple	1.0mm nickel-chromium armored (K type) imported thermocouple
Temperature tolerance error	500~750ºC±5ºC;750~960ºC±10ºC
Glow wire U-shaped head	4mm imported nickel/chromium (80/20) wire
Glow wire moving speed

Electronic Glow Wire Flammability Test Apparatus Horizontal Burning Tester Chamber 3
